500Brinell
Non-drop design
Naturally it has been our aim to design and produce a bucket
that does not allow spillage. What is the point of having a
large volume bucket if you cannot fill it properly, or if material
spills out of it?Therefore our buckets have sides that are
laser-cut. The result is a bucket design where the rear edge
and the front edge in particular are especially high. It is now
possible to fill the bucket completely. You have complete
control of thematerial and the bucket does not spill any
material.
1.
The buckets have a rounded bottom and
conical shape. Numerous small folds make for a
durable bucket and the conical design allows for
simple filling and complete emptying.
6.
The implement hooks contribute to
the strong design. You will notice that
hooks and locking holes are positioned
along a fold in themetal. Depending on
bucket model and size, theremay be a
double profile sheet inside the bucket.
2.
The upper edge of the bucket back ends with
a U-beam. On the HD and HDV buckets this area
has an additional angle profile welded all along
the width of the bucket.
3.
The sides have side reinforcements that
make themeven stronger. At the very bottom
there is welded a triangular wear-piece, which
simultaneously stabilises the cutting edge. On
the HD buckets, this wear-piece runs all the way
up along the side.
4.
All buckets have extremely durable cutting
edges (500 HB). Depending on bucket model
and size, 12, 16 or 20mm thick and 100, 150 or
200mmwide cutting edges are used. Together
with the parallel wear-pieces this makes the
bucket bottom strong, resist torsion and hard-
wearing.
5.
In order to have even greater torsional
strength and stability, the wider buckets are
fitted with an additional, profiled back-plate
(not on L and LVmodels). Using a special overlap
design, the HV buckets have a hole profile along
the implement hooks and this makes these
large buckets stronger andmore stable.
The non-spill bucket
Buckets for all needs
All buckets are conical and easy to fill, because thematerial does not have to
be forced into the bucket. The conical, “hopper-shaped” design also allows
for rapid and complete emptying of the bucket. Whatever your needs are
or what demands you have, youwill be able to find your newbucket in our
range. There are a total of 11 different models and 37 versions. There is also
a grading bucket plus several special buckets such as amulti-function
bucket, snow clearing bucket and a high-tip bucket.
