MULTIBENNE
130
150
170
190
210
230
250
Width, cm
130
150
170
190
210
230
250
Depth, cm
80
80
80
80
80
80
80
Volume, m
3
0.66
0.76
0.86
0.96
1.07
1.17
1.27
Number of tines in the grabber 7
8
9
10
11
12
13
Weight, kg
280
304
360
386
423
447
477
MAXIGRAPPLE
210
210T
240
240T
260
260T
Width, cm
210
210
240
240
260
260
Depth, cm
81
81
86
86
86
86
Teeth, cm
–
24
–
24
–
24
Weight, kg
605
620
640
655
710
730
Multibenne
™
THE PERFECT ALL-ROUND IMPLEMENT
If you have a diet feeder that has to be loadedwith various
feeds, Multibenne is your best choice. The requirements and
demands towhichwe have paid particular attention are: It
should be perfectly suited for its purpose – namely silage
handling. Therefore the sides are tapered so that they can
be insertedmore easily into the silage. When the implement
crowded back the side plates are utilised so that loose
material is not lost. A relatively short bottomsectionmakes
it easier to fill the bucket, all theway to the back. In this way,
the centre of gravitymoves towards the loader andwhen
unloading into high-sided vehicles, the bucket tip does not
enter too far into them. The closed bottomsection and the
close spacing of the tines result in reduce losses fromspillage.
The closed bottompiece of the bucket ensures that all thema-
terial is always completely gathered up. Multibenne, designed
according to the same principles as Silograb, can handlemany
different types of fodder andmanure aswell. Therefore you
need not change implementswhen feeding your animals.
Maxi Grapple
™
HIGH CAPACITY AND FLEXIBILITY
The bucket is based on the sturdy and reinforced HD bucket.
The grapple arm ismounted to the rear of the bucket and this
contributes to the power of this implement. Themoving upper
section of press-formed profiles is fittedwith sturdy bear-
ings, three-layer bearings and heavy pivot pinswith heavy-
duty locks. The sectionwith the powerful teeth is bolted on.
Stress and torsion forces are in thisway transmitted to the
entire implement. The teeth (version T) are simply attached
in the bucket bottom. The protectivemesh is a safety device
that preventsmaterial from falling onto the tractor (optional
extra). It is strongly recommended especially if the loader is
without parallel linkage or for tractorswithout a cab.
Maxi Grapple is used particularly in the US and Canada for
handling round bales (large 2mopening), loose hay, brash and
branches, loose silage, manure and for bucket work gener-
ally. Teeth, protectivemesh and the grapple armare easy to
removewhen you need to use just the bucket.
SILAGE IMPLEMENTS
